The Multi-Function CNC Segment Difference Grinder M7 represents a precise engineering solution designed to tackle complex grinding tasks with absolute control. Weighing in at a solid 1300kg, the heavy-duty cast-iron foundation actively absorbs operational vibrations, ensuring that every micromillimeter of movement remains strictly regulated. When powering up the 7.5kw spindle, operators will notice a steady, balanced hum rather than erratic mechanical noise, which signals superior concentricity and alignment. This machine is engineered to handle demanding material removal while maintaining strict dimensional tolerances across extended production runs. We have designed the M7 to serve as the reliable core of your grinding operations, translating raw metallic rods into finished, highly accurate tooling components without hesitation.
SPECIFICATION | M7 |
Xaxis route: | 420mm |
Yaxis route: | 250mm |
Caxis route: | -45~100° |
A axis route: | 00 |
A2 axis route: | 220mm |
2 axis route: | 220mm |
axis route: | 400mm |
Control motor type | servo motor x7 axis |
Spindle power: | 7.5kw |
Spindle maximum RPM: | 8000 |
Dimension/Weight: | 1450*1990*2000mm/1300kg |
The architectural philosophy behind the M7 grinder centers on minimizing manual operator intervention while maximizing output consistency. By integrating proprietary software and intelligent mechanical modules, this grinder transforms complex, multi-step machining into a straightforward, continuous operation that elevates your facility's production capabilities.
Our originally developed operation software features an intuitive 3D graphical interface that bridges the gap between digital blueprints and physical execution. Operators benefit from "one-click" smart programming combined with real-time 3D simulation and anti-collision detection. This visual environment significantly lowers the learning curve for programming complex three-dimensional segment difference structures, allowing your team to visualize the exact grinding path before the wheel ever touches the metal.
The M7 is built to automatically feed and collect material, operating as a true multi-function unit with one-time feed only. We utilize a patented modular grinding head system that allows operators to rapidly switch between internal/external cylindrical grinding, end face grinding, and taper grinding. This means multiple functions—processing for rod section difference, end face chamfer, flat end face, even water slot, ball head, round angle, and polygon shapes—are executed sequentially without requiring manual repositioning or secondary setups.
To preserve the structural integrity of your materials, the grinder incorporates a constant pressure grinding mechanism alongside an intelligent cooling device. This targeted coolant delivery prevents workpiece burns and thermal deformation, effectively increasing processing efficiency by over 30%. Furthermore, the M7 is ready for the modern digital factory. It supports direct MES system docking and remote equipment monitoring, ensuring that production data flows transparently across your facility's management network.
Beyond its software intelligence, the physical execution of the M7 relies on a highly synchronized mechanical framework. The core function revolves around a 7 axis CNC linked motion, specifically used for removing rod margin to dramatically improve the efficiency of tool production. As the servo motors drive the axes, the machine maintains a rigid grip on the workpiece, ensuring that aggressive material removal does not compromise the final surface finish.
Equipped with an advanced online detection system, the M7 utilizes an automatic tool setter and laser measurement technology to monitor the machining process in real time. This allows the system to apply automatic compensations on the fly, guaranteeing strict consistency across large batch runs. Whether your facility is processing tungsten carbide, advanced industrial ceramics, or specialized high-speed steel, the machine adapts its grinding pressure and feed rates to suit these notoriously difficult-to-machine materials. From initial R&D prototyping to full-scale continuous manufacturing, the results remain predictable and precise.
Workpiece Accommodation: The workhead securely holds a wide variety of stock sizes, featuring a clamp diameter range of 1-25mm to suit diverse tooling requirements.
Length Capacity: The structural envelope is engineered to manage extended workpieces, supporting a tool length of 250mm without introducing deflection or chatter.
Flute Processing: The machine's internal travel limits allow for deep, continuous grinding operations, accommodating a tool maximum flute length of 140mm.
Investing in advanced grinding technology requires more than just receiving a machine on the shop floor; it demands a comprehensive partnership. We provide an end-to-end service lifecycle that begins long before the M7 is powered on. Our engineering team assists with initial equipment selection and conducts specialized process development tailored to your specific material and geometric requirements.
Once the machine is integrated into your facility, we deliver professional, hands-on technical training for your operators. This ensures your staff can confidently navigate the 3D software, manage the automated feeding systems, and perform routine maintenance. By focusing on deep operator understanding and proactive support, we help you maximize machine uptime, reduce raw material waste, and maintain the precise tolerances your clients demand.
